MCB C80, 10kA, 4P
NST
PELEMCB04C80L
Valid Article
HS Code:
853690
Last Updated on:
30/04/2025, 22:03:13
OC subscriptions: included in supply or field order tools (e.g. UniField)
|
|
SC subscriptions: included in supply or field tools
|
|
OC validations: approved for procurement and use by an OC for international or local orders specifying context and activity in Medical Standard Lists (MSL)
|
|
MCB C80, 10kA, 4P
Form
- Circuit breaker 4 pole, 80 Amps, C Curve 10 kA Icu conforming to EN/IEC 60947-2, 230 - 400 V AC 50/60 Hz. Thermal-magnetic.
- Single terminal, top or bottom rigid wire(s) 1-50 mm² max
- Single terminal, top or bottom flexible wire(s) 1-35 mm² max
- Operational temperature: -35 +70 °C
- Height: 81mm
- Width: 108mm
- Depth: 73mm
- Weight 0.82kg
Open article.
Fit
Compatible with main circuit and distribution boards of similar make and technical specifications.
Function
MCBs or Miniature Circuit Breakers are electromechanical devices which protect an electrical circuit from an over current.
A MCB functions by interrupting the continuity of electrical flow through the circuit once a fault is detected.
